| GEARBOX / 100HP / 1:1.46 / 20 SPLINE |
|
*Horsepower: 100hp |
|
|
|
* Fit several Howse, King Kutter, Bush Hog, Rhino, Land Pride and most brand of mowers |
|
|
|
*Outside rotation: clockwise or counterclockwise with no modifications |
|
|
|
*Comes with the castellated nut |
|
|
|
*Housing construction: Ductile iron |
|
|
|
*Input Shaft: 1-3/4 inch 20 Spline Shaft
|
|
|
|
*Input Shaft center to the base flange is 7-3/16"
|
|
|
|
*Gear ratio: 1:1.46 |
|
|
|
*2 in. diameter, 15 Spline Output Shaft |
|
|
|
*Mounting Pattern: (4) 3/4" holes, 8" diameter bolt pattern |
|
|
|
*Shipped dry, please add 16OZ 80-90W gear lube before using |
|
|
|
*Weight: 82.50lbs |
|
|
