45PRC30147-N, 40HP Rotary Cutter GEARBOX, 1:1.47, SHEARPIN
| RC30 GEARBOX / 1:1.47 / SHEAR PIN | ||
|
*Horsepower: 40
|
||
|
*For 4 ft., 5 ft., and 6 ft. rotary cutters
|
||
|
*Turns both clockwise or counterclockwise
|
||
|
*Comes with the castellated nut
|
||
|
*Housing construction: Ductile iron
|
||
|
*Smooth input shaft: 1-3/8 in.
|
||
|
*Output shaft 1.57 in. 12 Spline
|
||
|
*Gear type: Bevel gear
|
||
|
*Bolt pattern: (4) 5/8" diameter holes on a 6-3/4 in. bolt circle
|
||
|
*4-3/4" Bolt Hole Centers for Mounting
|
||
|
*Gear ratio: 1:1.47
|
||
|
*Input Shaft centre to the base flange is 6.43"
|
||
| *Output shaft length from the base flange is 5.35" | ||
|
*Shipped dry, please add 16OZ 80-90W gear lube before using
|
||
|
*Weight: 47.30lbs
|
||
