45PRC30147-1N, 40HP GEARBOX, 1:1.47, 6 SPLINE

SKU: 45PRC30147-1N
5.0 1 review
$199.99

1-Year Warranty

Ship Next Business Day

Canada Delivery Available
Contact Us Via Phone
Contact Us Via Email

Shipping Calculator

Notes: * Please add items to your shopping cart before clicking the Calculate Shipping button.

Notes: * Please add items to your shopping cart before clicking the Calculate Shipping button.
Specifications

RC30 GEARBOX / 1:1.47 / 6 SPLINE
*Horsepower: 40
*For 4 ft., 5 ft., and 6 ft. rotary cutters
*Turns both clockwise or counterclockwise
*Comes with the castellated nut
*Housing construction: Ductile iron
*6 spline input shaft: 1-3/8 in.*Gear ratio: 1:1.47
*Gear type: Bevel gear
*Bolt pattern: (4) 5/8" diameter holes on a 6-3/4 in. bolt circle
*Output shaft 1-1/2 in. 12 Spline
*4-3/4" Bolt Hole Centers for Mounting
*1-3/8"-6 spline input shaft, 1.57" X 12 tapered spline output shaft
*Shipped dry, please add 16OZ 80-90W gear lube before using
*Weight: 47.30lbsShip via UPS.
